Alpha Wire Alpha Essentials Communication & Control Control Cable, 2 Cores, 0.56 mm², Screened, 30m, Grey PVC Sheath,
Techniniai dokumentai
Specifikacijos
Markė
Alpha WireSerija
Alpha Essentials
Serija
Alpha Essentials Communication & Control
Number of Cores
2
Cross Sectional Area
0.56 mm²
Screened/Unscreened
Screened
Ilgis
30m
Cable Shape
Round
Sheath Colour
Grey
American Wire Gauge
20 AWG
Outer Diameter
4.67mm
Sheath Material
PVC
Standards Met
CE, CSA, UL
Armoured
No
Core Strands
7/0.32 mm
Minimum Bend Radius
10 x Diameter
Conductor Material
Tinned Copper
Įtampos reitingas
300 V
Earth Cable
No
Drain Wire
Yes
Screen Type
Foil
Maksimali darbinė temperatūra
+75°C
Conductor Resistance
33.46 Ω/km
Insulation material
PE
Minimali darbinė temperatūra
-20°C
Kilmės šalis
United States
Produkto aprašymas
Single-Core 0.32 mm2 to 0.52 mm2, Complete Foil Shielding
The Alpha Wire control and communcation cables can be used to for many applications including banking systems, data transmission, control systems and many more.
The cables contain 2 to 4 conductor copper cables, fully screened using aluminised tape and a tinned copper drain. The cable contains a colour coded polyethelene insulation and is shielded by a grey PVC coating. The component can survive temperatures of -20°C to +60°C and is approved by UL 2092 and UI VW-1.
RS Industrial Cable
Cables designed to meet the special requirements of high speed data transmission systems associated with data processing or information systems; also for process and control applications.
Sandėlio informacija laikinai nepasiekiama.
Patikrinkite dar kartą.
€ 56,70
1 Reel of 30 Metres (be PVM)
€ 68,61
1 Reel of 30 Metres (su PVM)
1
€ 56,70
1 Reel of 30 Metres (be PVM)
€ 68,61
1 Reel of 30 Metres (su PVM)
1
Pirkti dideliais kiekiais
| kiekis | Vieneto kaina |
|---|---|
| 1 - 4 | € 56,70 |
| 5 - 9 | € 54,60 |
| 10+ | € 52,40 |
