Fluke 190 ScopeMeter 190 II Series, 200MHz Handheld Oscilloscope, 2 Analogue Channels
Techniniai dokumentai
Specifikacijos
Markė
FlukeNumber of Analogue Channels
2
Bandwidth
200MHz
Digital/Analogue
Digital
Oscilloscope Type
Handheld
Serija
190 II
Sample Rate Random
2.5 Gsps
Interface
USB
Power Source
Battery, Mains
Display Type
LCD
Minimum Vertical Sensitivity
2mV/div
Maximum Vertical Sensitivity
100V/div
Minimum Time Base
2ns/div
Screen Size
6in
Record Length
10000 points/ch, 30000points/ch
Weight
2.1kg
Battery Type
Rechargeable Li-ion
Vertical Resolution
8 bit
Maximum Time Base
4s/div
Matmenys
190 x 70 x 265mm
Battery Life
4 h
Safety Category
CAT III 1000 V, CAT IV 600V
Rise Time
1.7ns
Kilmės šalis
Netherlands
Produkto aprašymas
Fluke Industrial ScopeMeter 190 Series II
The 190 Series ScopeMeters are the first two and four channel industrial portable oscilloscopes allowing measurements in harsh, hazardous and dirty environments with the highest CAT IV 600V safety rating. With these features the ScopeMeter 190 Series II can be used for measurements in Single-phase and Three-phase industrial distribution up to outside and service entrance. The standard features like TrendPlot™, Connect-and-View™ triggering, and ScopeRecord™ allow quick diagnosis of industrial machinery, automation and process controls problems. The Automatic capture and the display of the last 100 screens allows the review of observed anomalies.
Supplied with
Set of 4 probes (4-channel models) or 2 probes (2-channel models), handstrap (fixed to instrument), hanging strap, USB cable, Li-ion battery BP290, a FlukeView demo package and user manuals on CD-ROM
Fluke Industrial ScopeMeters
The small, lightweight hand held digital oscilloscopes are ideal for use by technicians working in service, maintenance and installation applications. Features include:
Sandėlio informacija laikinai nepasiekiama.
Patikrinkite dar kartą.
€ 5 567,00
už 1 vnt. (be PVM)
€ 6 736,07
už 1 vnt. (su PVM)
Calibration type
No Calibration
1
€ 5 567,00
už 1 vnt. (be PVM)
€ 6 736,07
už 1 vnt. (su PVM)
Calibration type
No Calibration
1
