Recom RS DC-DC Converter, ±12V dc/ ±83mA Output, 18 → 36 V dc Input, 2W, Through Hole, +85°C Max Temp -40°C Min
Techniniai dokumentai
Specifikacijos
Markė
RecomOutput Voltage
±12V dc
Input Voltage Range
18 → 36 V dc
Galingumas
2W
Input Voltage Nominal
24 V dc
Output Current
±83mA
Tvirtinimo tipas
Through Hole
Isolated
Yes
Number of Outputs
2
Package
SIP
Isolation Voltage
500V ac
Gylis
11.1mm
Ilgis
21.8mm
Serija
RS
Load Regulation
±0.5%
Minimum Temperature
-40°C
Efficiency
83%
Maximum Temperature
+85°C
Kilmės šalis
Taiwan, Province Of China
Produkto aprašymas
Recom 2W SIP Single/Dual Output Regulated Isolated DC-DC Converter - RS Series
High power-density, an industrial temperature range of -40° to +85°C.
Additional features such as Remote-On-Off control make these converters ideal for highly sophisticated industrial designs.
Standards
EN60950-1
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
€ 21,10
€ 21,10 už 1 vnt. (be PVM)
€ 25,53
€ 25,53 už 1 vnt. (su PVM)
Standartas
1
€ 21,10
€ 21,10 už 1 vnt. (be PVM)
€ 25,53
€ 25,53 už 1 vnt. (su PVM)
Sandėlio informacija laikinai nepasiekiama.
