Fluke 725EX Multi Function Calibrator, 24mA, 30V, 200 x 96 x 47mm - RS Calibration

Fluke Multi Function Calibrator

The Fluke multifunction calibrator is used to test and calibrate almost any process parameter. It can be used to measure and source current ranging from 0mA to 24mA, volts, temperature (RTDs and thermocouples), frequency, ohms, and pressure, using optional pressure modules to test and calibrate almost any process parameter. Its split display lets you view input and output values simultaneously. For valve and I/P tests, you can source mA while measuring the pressure. This calibrator has auto-stepping and auto-ramping for remote testing, plus 25% stepping for fast linearity tests. It is supplied with a pair of TL75 test leads, AC72 test clips and stackable test leads, 4xAA alkaline batteries and user manual on CD-ROM.

Features and Benefits

•
  Small, streamlined shape makes it easy to carry
  Rugged, reliable design stands up to field use
  Measure and source thermocouple type J,K,T,E,R,S,B,L,U,N,XK,BP
  Measure and source RTDs NI-120,PT100,PT500,PT1000
  Easy to read measure/source screen lets you view input and output simultaneously
  Measure/source pressure using any of 29 Fluke 700Pxx pressure modules
  Easy to operate and user-friendly menu control
  Source mA with simultaneous pressure measurement to conduct valve and I/P tests
  Support flow meter testing with frequency and CPM functions
  Perform fast linearity tests with auto-step and auto-ramp features
  Power transmitters during test using loop supply with simultaneous mA measurement
  Handling of fast pulsed RTD transmitters and PLCs, with pulses as short as 10ms
  Store frequently used test setups for later use
  Operating temperature ranges between –10°C and 55°C
  Backlight lets you work in poor light
  Large battery capacity of four AA cells
  Battery door for easy changes

Applications

•
  Process control automation
  Manufacturing
  Instrumentation

Certifications

•
  CE certified
  CSA certified
  ATEX certified
